TS 5000 ECline
ECline guide rail TS 5000 * For TS 5000 ECline closer body with opening assistance
- Opening assistance for easy opening and comfortable passing of the door
- Opening assistance can be switched off for doors with wind load or pressure differences
- Easy to replace with the standard guide rail
- With screwed slide block
Application Areas
- Barrier-free access with strongly decreasing opening torque
- Single leaf doors
- Installation on hinge side
- Right and left single-action doors
Technical data
| ECline guide rail TS 5000 | |
| Length | 452.5 mm |
| Width | 33 mm |
| Height | 30 mm |
| Integrated opening assistance | Yes |
| Hold-open function | Optional |
| Opening assistance can be switched off | Yes |
Downloads
ECline guide rail TS 5000
LABELLING OBLIGATION: © GEZE GmbH
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
